Запчасти Case CX31B (5.0038[02]) - LONG ARM LINES - 747323070 (35) - HYDRAULIC SYSTEMS

1

87376220

HOSE,9.50 mm ID x 1570.00 mm

1шт.

2

87376221

HOSE,9.50 mm ID x 5105.00 mm

1шт.

3

87542808

CLIP

1шт.

4

72951373

GASKET

1шт.

5

11106034

BOLT,Hex, M10 x 20, 10.9, Full Thd

1шт.

6

10571879

LOCK WASHER,10.2mm ID x 18.1mm OD x 2.2mm Thk

1шт.

7

87375178

FLEXIBLE HOSE

2шт.
