Запчасти Case CX31B (400-72[1]) - HYDRAULIC LINES, LOW ANGLE DOZER (56) - GRAPE HARVESTER SHAKERS

PW02H00023F1

Hyd , Low

1шт.

a1

HX35L06110DY

HOSE

4шт.

a2

HX23L04110DX

HOSE,6.3mm ID x 1100mm L

2шт.

a3

PW02H01014D3

HOSE

2шт.

a4

PW01P01003DC

HOSE,45mm ID x 730mm L

2шт.

a5

PX02H01001P1

GROMMET

4шт.

a6

PW02H01002DP

HOSE

2шт.

a7

PH02H01052D6

HOSE

1шт.

a8

PH02H01052D8

Hose

1шт.

a9

PY01P01043D5

CABLE TIE,301mm L

1шт.

PX19H00005F1

HYD TUBE

Hyd , Swivel

1шт.

b1

HH25S06006G1

HYD CONNECTOR

4шт.

b2

HH35S06006G1

90 ELBOW,90 Degree, 3/8" PF x 3/8" PF x 60mm L

2шт.

b3

HH35S04006G1

90 ELBOW,90 Degree, 1/4" PF x 3/8" PF x 60mm L

2шт.

b4

HH35S04004G1

90 ELBOW

2шт.

b5

HH45S04004G1

45 ELBOW

2шт.

b6

ZE72X04000

PLUG

1шт.

PW12H00002F1

Hyd , Propel

1шт.

c1

HH25S06008G1

HYD CONNECTOR

4шт.

c2

HH25S04004G1

HYD CONNECTOR

2шт.

c3

HH25S04002G2

HYD CONNECTOR

2шт.

PW13H00001F1

Hyd , Cylinder (Dozer)

1шт.

d1

HH25S06006G1

HYD CONNECTOR

2шт.

PW13H00003F1

Hyd , Cylinder (Angle)

1шт.

e2

HH35S04006G1

90 ELBOW,90 Degree, 1/4" PF x 3/8" PF x 60mm L

Elbow

1шт.

e4

PW13H01003F1

45 ELBOW,45 Degree

Elbow

1шт.
