Запчасти Case CX31B (866-17[1]) - ARM ASSY, LONG 1.47M (36) - PNEUMATIC SYSTEM

PW12B00113F1

ARM

Arm , Long 1.47M

1шт.

a1

PW12B00114F1

ARM

Assy, Long

1шт.

a1-1

PW12B00115P2

Arm, Long

1шт.

a1-1p

PV12B01227P1

BLOCK

Tapped

2шт.

a1-1r

PX12B01185P1

BLOCK

Tapped

2шт.

a1-2

PW12B01237P2

BUSHING,40mm ID x 82mm OD x 55mm L

2шт.

a1-3

PW12B01209P2

BUSHING,45mm ID x 50mm OD x 31.5mm L

2шт.

a1-4

PX12B01177P2

BUSHING,45mm ID x 55mm OD x 55mm L

2шт.

a1-5

PW12B01208D1

COLLAR

1шт.

a1-6

PX12B01016P1

COLLAR

1шт.

PW12B00159F1

ARM

Arm , Long 1.47M (Nibbler & Breaker)

1шт.

a1

PW12B00176F1

ARM

Arm , Long

1шт.

a1-1

PW12B00161P1

Arm, Long

1шт.

a1-1a

PW12B00115P2

Arm, Long

1шт.

a1-1aa

PV12B01227P1

BLOCK

Tapped

2шт.

a1-1ab

PX12B01185P1

BLOCK

Tapped

2шт.

a1-1b

PW12B01277P1

PLATE

1шт.

a1-2

PW12B01237P2

BUSHING,40mm ID x 82mm OD x 55mm L

2шт.

a1-3

PW12B01209P2

BUSHING,45mm ID x 50mm OD x 31.5mm L

2шт.

a1-4

PX12B01177P2

BUSHING,45mm ID x 55mm OD x 55mm L

2шт.

a1-5

PW12B01208D1

COLLAR

1шт.

a1-6

PX12B01016P1

COLLAR

1шт.

PW12B00122F1

Arm Instal

1шт.

b1

PX12B01370P1

PIN

1шт.

b2

PW02B01205P1

Pin

1шт.

b3

HS18C10085G2

BOLT

Cap

1шт.

b4

ZS18C16035

SCREW,Hex, M16 x 35mm

Cap

1шт.

b5

ZW16H16000

WASHER

1шт.

b6

PW12B01242P1

WASHER

1шт.

b7

ZN18C10008

NUT

2шт.

b8

PR02B01108P1

SHIM,0.5mm Thk

(0.5)

2шт.

b9

PR02B01121D1

SHIM,47mm ID x 70mm OD x 0.9mm Thk

(0.9)

1шт.

b10

PW02B01239P1

SHIM,0.5mm Thk

(0.5)

1шт.

b11

PW12B01243D1

SHIM,0.5mm Thk

(0.5)

1шт.

b12

PW12B01243D2

SHIM,0.9mm Thk

(0.9)

2шт.

PX12B00134F1

Arm Group

1шт.

c1

PX12B01371F1

LINK CONROD

Link , Bucket

1шт.

c1-1

PX12B01372P1

LINK CONROD

Link, Bucket

1шт.

c1-2

PX12B01151P1

BUSHING,40mm ID x 50mm OD x 50mm L

2шт.

c1-3

PX12B01246P1

BUSHING,40mm ID x 50mm OD x 32mm L

2шт.

c1-4

PW12B01208D2

COLLAR

1шт.

c2

PW12B01224P2

LINK

2шт.

c3

PW12B01351P1

PIN

2шт.

c4

PX12B01319P1

PIN

1шт.

c5

PW12B01311P1

PIN,40mm OD x 210mm L

1шт.

c6

ZS18C16030

SCREW,Hex, M16 x 30mm

Cap

2шт.

c7

ZW16H16000

WASHER

2шт.

c8

PW12B01216P1

WASHER

2шт.

c9

PN54D01001D3

SEAL,40mm ID x 50mm OD x 4mm Thk

Dust

10шт.

c10

2445R138D20

SEAL,45mm ID x 55mm OD x 4mm Thk

Dust

2шт.

c11

ZG91S02000

LUBE NIPPLE,1/8" NPT x 1/8" NPT

Grease

5шт.

c12

ZG91U02000

LUBE NIPPLE

Grease

2шт.

c13

PR12B01113P1

SHIM,0.5mm Thk

(0.5)

4шт.

c14

PR02B01123D1

SHIM,0.9mm Thk

(0.9)

4шт.
