(HC300-01[3]) - MOTOR ASSY (SWING)

Запчасти Case CX31B (HC300-01[3]) - MOTOR ASSY (SWING) (00) - GENERAL & PICTORIAL INDEX

Схема запчастей Case CX31B - (HC300-01[3]) - MOTOR ASSY (SWING) (00) - GENERAL & PICTORIAL INDEX
101
103
102
701
601
171
901
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

80

LQ15V00007S015

PLUG

2шт.

85

NSS

NOT SOLD SEPARAT

Name Plate

1шт.

86

NSS

NOT SOLD SEPARAT

Pin

2шт.

PM15V00014R100

REPAIR KIT

Consists Of Item 36x3, 37x1, 53x1

1шт.

PM15V00014R200

REPAIR KIT

Consists Of Item 42x1, 50x9

1шт.

PM15V00014R400

REPAIR KIT

Consists Of Item 66x1, 67x1, 68x1

1шт.

PW15V00016R400

REPAIR KIT

Consists Of Item 23x1

1шт.

PX15V00024R500

REPAIR KIT

Consists Of Item 1x1, 2x1, 3x1, 4x1

1шт.
