Запчасти Case 570NXT (33.202.BN[02]) - BRAKE PEDAL RIGHT (33) - BRAKES & CONTROLS

1

84328348

PEDAL

Brake RH

1шт.

2

412250

NUT,M8 x 1.25, Cl 8

4шт.

3

230973A1

SPRING,Extension, 23.876mm OD x 93.47mm L

Brake Return

1шт.

4

412479

BOLT,Hex, M8 x 1.25 x 35mm, Cl 8.8

2шт.

5

A77310

SUPPORT,0.754" ID x 1.375" OD x 0.81"

2шт.

6

87655042

SPECIAL WASHER,8.8mm ID x 17.5mm OD x 2.2mm Thk

M8

4шт.

7

412250

NUT,M8 x 1.25, Cl 8

4шт.

8

87655047

SPECIAL WASHER,21.25mm ID x 38.10mm OD x 4.20mm Thk

M20

2шт.

9

D124529

SPACER,19.5mm ID x 35mm OD x 12mm Thk

Brake Shaft

2шт.

10

D124530

PIN,15.85mm OD x 111mm L

Brake Pedal Lock

1шт.

11

138-328

LOCK PIN,5/16" x 2 1/2", Slotted

Pedal Lock

1шт.
