1
BMF31E
DRY BATTERY
12V; Models Without Cold Start
1шт.
2
D83485
CABLE,300mm L
Negative Ground
1шт.
3
86050286
FLANGE BOLT,M10 x 20mm, Cl 8.8
Negative battery cable ground, bolt to chassis
1шт.
4
144171A1
CABLE
1500 mm; Positive; Incl. 5
1шт.
5
383619R1
COVER
1шт.
6
814-10245
BOLT,Hex, M10 x 1.5 x 245mm, Cl 8.8
M10 x 245 mm
2шт.
7
D125079
BRACKET
Battery Hold-Down
2шт.
8
D55561
RETAINER
1шт.
9
495-11041
WASHER,0.406" ID x 0.812" OD x 0.065" W
(13/32 x 13/16 x 1/16")
2шт.
10
D127018
STRAP
2шт.
11
9804261
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
1шт.
12
493-11039
LOCK WASHER,3/8", Int-Ext Tooth
2шт.
13
86625263
WASHER,9mm ID x 20mm OD x 1.6mm Thk
2шт.
14
43362
NUT,M8 x 1.25, Cl 10
1шт.
15
412479
BOLT,Hex, M8 x 1.25 x 35mm, Cl 8.8
1шт.
16
257279A1
GROMMET
Battery Cable; Mounts In Chassis Side Channel
2шт.
17
83990583
LOCK WASHER,M8 x 14.8mm OD x 2.1mm Thk
1шт.
