Артикул
Название
Примечание
Количество
A77994
GASKET KIT
Basic Service Engine, Incl. 1 - 21
1шт.
1
222-993
GASKET,3/8 Tube, Fl, Copper
See Figure 02-14
2шт.
3
637-62081
O-RING,1.6mm Thk x 8.1mm ID, Cl 6, 90 Duro
See Fig 03-06
1шт.
6
J902425
SEALING WASHER,22.2mm ID x 26.9mm OD x 1.75mm Thk
See Figure 02-17
1шт.
8
J903475
SEALING RING,72.39mm ID x 90.39mm OD x 9mm Thk
See Figure 02-12
1шт.
10
J906696
SEAL,41mm ID x 43mm OD x 2.5mm H
38 mm ID; See Figure 02-22, 02-23
1шт.
11
J906697
SEAL,Square, 5.16mm Thk x 50.17mm ID
50 mm ID; See Figure 02-22, 02-23
1шт.
12
J909356
SEAL,Square, 1.68mm Thk x 15.6mm ID, -16
See Figure 03-07
4шт.
13
J910517
O-RING
See Figure 02-22, 02-23
1шт.
14
J912473
SEAL,157mm ID x 163.18mm OD x 7.03mm Thk
SEALRING See Figure 02-25
1шт.
17
J930324
SEAL
0,5 mm; Not Used In This Application
4шт.
19
J938153
MANIFOLD GASKET,0.8mm Thk
See Figure 02-13
1шт.
20
J935032
SEAL
80 mm ID; See Figure 03-06
1шт.
21
SEALING WASHER,11.71mm ID x 19.3mm OD x 1.27mm Thk
12 x 19 x 1,5 mm; Replaces J935171; See Figure 03-05
4шт.
Выбрано товаров: 22
