Запчасти Case 570MXT (08-05) - HYDRAULICS - CYLINDER, LOADER CLAM (08) - HYDRAULICS

1

358237A1

VALVE

Loader Control Valve; Three Spool; See Figure 08-15, For Mounting, See Figure 09-01

1шт.

2

218-5062

HYD CONNECTOR,7/8"-14, 37 Degree x 7/8"-14, O-Ring

Incl. 3

2шт.

3

237-6010

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

1шт.

6

814-10040

BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8

2шт.

7

D138055

CLAMP

2шт.

8

120303A1

SPACER,11mm ID x 15.82mm OD x 15mm Thk

2шт.

9

892-11010

LOCK WASHER,M10

2шт.

10

829-1410

NUT,M10 x 1.5, Cl 10.9

2шт.

11

138467A1

HOSE,12.7mm ID x 680mm L

680 mm (26-3/4 in)

2шт.

12

196824A1

TUBE

Upper Clam Port; Used With 87426379 Loader Arm, See Figure 09-04

1шт.

12a

87611328

HYD TUBE,15.88 mm OD x 1761 mm L

Upper Clam Port; Used With 87566994 Loader Arm, See Figure 09-04A

1шт.

13

196821A1

TUBE

Lower Clam Port; Used With 87426379 Loader Arm, See Figure 09-04

1шт.

13a

87611326

HYD TUBE,15.88 mm OD x 1761 mm L

Lower Clam Port; Used With 87566994 Loader Arm, See Figure 09-04A

1шт.

14

D138055

CLAMP

4шт.

15

829-1410

NUT,M10 x 1.5, Cl 10.9

4шт.

16

892-11010

LOCK WASHER,M10

4шт.

17

218-776

PLUG,7/8"-14, 37 Degree

Not Used On Models With Clam Bucket

2шт.

19

232945A1

TUBE

Lower Clam Port

1шт.

20

218-435

HYD CONNECTOR,7/8" - 14 Male JIC x 7/8" - 14 Male JIC

1шт.

22

360937A1

TUBE

Lower Clam Port

1шт.

23

360916A1

TUBE

Upper Clam Port; Models Without Husco Loader Valve

1шт.

23

87447352

TUBE,.625" OD

Upper Clam Port; Models With Husco Loader Valve

1шт.

24

360918A1

TUBE

Lower Clam Port; For Service, Order 19, 20, 22; Models Without Husco Loader Valve

1шт.

24

87447350

TUBE,11.66 mm ID x 15.88 mm OD

Lower Clam Port; Models With Husco Loader Valve; For Service Order Ref 20, 22 & 87313507 Tube at Loader Valve

1шт.
