(6-188) - RANGE TRANSMISSION, IN REAR FRAME (CONTD)

Запчасти Case 380B (6-188) - RANGE TRANSMISSION, IN REAR FRAME (CONTD) (06) - POWER TRAIN

Схема запчастей Case 380B - (6-188) - RANGE TRANSMISSION, IN REAR FRAME (CONTD) (06) - POWER TRAIN
26
25
22
23
27
21
24
22
23
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

21

A27089

SNAP RING,2.36mm Thk, Ext

RING - retaining snap

1шт.

22

3112846R1

THRUST WASHER

WASHER - thrust

2шт.

23

3113041R91

ROLLER CAGE BEARING

- needle, reverse idler gear

2шт.

23

3112844R91

BEARING, NEEDLE

BEARING - needle, Serial Range: (Optional-3113041R91)

2шт.

24

3112845R1

SPACER

- idler bearing

1шт.

25

70298C1

PINION

GEAR - reverse idler, 20 and 24 teeth

1шт.

26

399838R3

SHAFT

- reverse idler

1шт.

27

366281R1

PIN,3/8" x 2", Coiled

1шт.
