Запчасти Case 380B (4-14) - BATTERY TRAY, BATTERY AND CABLES (03) - FUEL SYSTEM

1

A186026

BATTERY, DRY

dry charge, maintenance free, 12 volt

1шт.

2

3116240R1

CLIP

0.56 diameter, closed (Starter motor cable)

1шт.

3

527605R3

ROD

battery hold down

2шт.

4

3121178R1

BRACKET

battery hold down (12 volt battery)

1шт.

5

495-11034

WASHER,5/16", SAE

(Flat, 11/32 x 11/16 x 1/16")

2шт.

6

425-105

NUT,5/16"-18, G5

2шт.

7

63-1086

SCREW,Hex Hd, #8-32 x 3/8"

hex, No. 8 NC x 3/8 inch

1шт.

8

92-11008

LOCK WASHER,#8

1шт.

9

225-10108

NUT,#8-32

1шт.

10

537504R1

CABLE ASSY.

, Serial Range: battery-ground

1шт.

11

528301R1

CABLE ASSY.

, Serial Range: battery-starter

1шт.

12

493-11052

LOCK WASHER,Ext-Int Tooth, 1/2"

lock, internal/external tooth, 1/2 inch

2шт.

13

NSS

NOT SOLD SEPARAT

GASKET - foam, 32.7 inch (Cut from 73217C2)

1шт.

13

73217C2

FILLING STRIP

SEAL - foam, bulk length, 4 foot roll (1.2 metre)

1шт.

14

1536118C1

TRAY ASSY.

battery

1шт.

15

413-612

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5

2шт.

16

495-11041

WASHER,0.406" ID x 0.812" OD x 0.065" W

Flat, (13/32 x 13/16 x 1/16")

4шт.

17

92-11025

LOCK WASHER,6.4mm ID x 12.37mm OD x 1.57mm Thk

1шт.

18

25-104

NUT,1/4"-20, G5

1шт.

19

3113841R1

MOLDING

edge, battery tray

1шт.

20

1970806C1

SUPPORT

battery tray

1шт.

21

495-81117

WASHER,.344" x 1" x .120"

flat, 11/32 x 1 x 7/64 inch

2шт.

22

492-11031

LOCK WASHER,5/16"

2шт.

23

425-105

NUT,5/16"-18, G5

2шт.

24

113-118

BOLT,Hex, 5/16" - 18 x 5/8", Gr 5

2шт.

25

92-11031

LOCK WASHER,5/16"

2шт.

26

9635082

NUT,5/16" - 18, Gr 5

2шт.

27

492-11038

LOCK WASHER,3/8"

2шт.
