Запчасти Case 380B (9-06) - RADIATOR GRILLE (09) - CHASSIS

1

94301C4

SUPPORT ASSY.

grille and hood

1шт.

2

492-11038

LOCK WASHER,3/8"

2шт.

3

413-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5

2шт.

4

413-616

BOLT,Hex, 3/8" - 16 x 1", Gr 5

2шт.

5

1343408C1

SCREEN

upper grille

1шт.

6

1343409C1

SCREEN

SCREEN - lower grille

1шт.

7

1334768C1

SELF-TAP SCREW,Hex, M5.5 x 15mm

8шт.

8

1343406C1

GRILLE

ASSEMBLY - front

1шт.

9

99854C1

SHIM

grille support

1шт.

10

825-2406

FLANGE NUT,M6 x 1, Cl 8.8

4шт.

11

321-4739

EMBLEM

Case

1шт.

12

321-141

NUT - push-on type

2шт.

13

3121205R91

HORN

warning

1шт.

14

413-412

BOLT,Hex, 1/4" - 20 x 3/4", Gr 5

2шт.

15

495-11028

WASHER,1/4", SAE

(flat, 9/32 x 5/8 x 1/16")

2шт.

16

3119440R1

LOCK NUT

hex, self-locking, 1/4 inch NC

2шт.

17

1333180C1

CLIP

side panel, front

2шт.

18

26110R1

LOCK NUT,1/4"-20, GC

hex lock, 1/4 inch NC, grade 8

4шт.
