Запчасти Case 42 (12[A]) - 1400 POUND COUNTERWEIGHT

1

31112

O-RING

COUNTERWEIGHT - 1400 lb.

1шт.

2

13-16104

BOLT,Hex, 1" - 8 x 6-1/2", Gr 5

4шт.

3

230-41116

NUT,1"-8, GA

NUT - lock (1" - 8 NC)

4шт.

4

D26116

ARM - support, R.H.

1шт.

5

D26117

ARM - support, L.H.

1шт.

6

13-1236

BOLT,Hex, 3/4" - 10 x 2-1/4", Gr 5

2шт.

7

92-12

LOCK WASHER,3/4"

WASHER, LOCK, 3/4"

2шт.

8

25-1012

NUT,3/4"-10, G5

2шт.

9

D26131

ROD - stabilizer, R.H.

1шт.

10

D26132

ROD - stabilizer, L.H.

1шт.

11

95-10

WASHER,5/8"

- standard wrot (11/16" I.D. x 1-3/4" O.D. x 9/64" thick)

2шт.

12

132-91

COTTER PIN,3/16" x 1"

Pin, Split (Cotter), 3/16" x 1"

2шт.

13

195-41

WASHER,5/8"

2шт.

14

230-4117

LOCK NUT,7/16"-14, GA

NUT - lock (5/8" - 11 NC)

2шт.
