Запчасти Case 3400 (018) - MOTOR CYLINDER BLOCK (10) - ENGINE

1

394156R91

CYLINDER BLOCK

BLOCK ASSEMBLY, cylinder

1шт.

2

404201R1

PLATE

bearing

1шт.

3

394162R1

RING

PILOT, bearing plate

1шт.

4

539256R1

PISTON ASSY

9шт.

5

394154R1

GUIDE

RETAINER slipper

1шт.

6

394155R1

RETAINER

slipper

1шт.

7

394157R1

SPRING

RETAINER

9шт.

8

394158R1

SEAT

spring

1шт.

9

532302R1

SPRING

spring, cylinder block

1шт.

10

394161R1

RETAINER

spring

1шт.

11

394159R1

GUIDE

spring

1шт.

12

394164R1

PIN

piston cylinder

1шт.

13

21015R1

SNAP RING,#212, 2.217, Int, Spiral

SPIROLOX internal retaining

1шт.
