Запчасти Case 3400 (039) - LOADER BOOM AND LINKAGE (82) - FRONT LOADER & BUCKET

1

535849R1

ROD

connecting

1шт.

648002

KNIFE

1/8" x 3/4"

1шт.

120394

WASHER,3/8", SAE

13/32 x 13/16 x .051

1шт.

2

161003C1

NO LONGER SERVICED

CLEVIS YOKE

1шт.

114494

NUT,Jam, 3/8"-24, G5

1шт.

138084

SPLIT PIN/SAFETY PIN

rod end, 3/8 x 1-3/32

1шт.

220257

PIN, SPLIT (COTTER)

PIN, COTTER 3/32 x 3/4

1шт.

3

535825R1

SPARE PART ASSEMBLY, range

1шт.

4

531784R1

SPARE PART KNOB, shift

1шт.

536743R1

PANEL

transmission control lever

1шт.

536728R1

DECAL

PRODUCT GRAPHIC, transmission control

1шт.
