Запчасти Case 26 (088) - TOOLS

Схема запчастей Case 26 - (088) - TOOLS

Артикул

Название

Примечание

Количество

1

D32049

TOOL

PLIERS - snap ring, Includes: Ref. 2 - 4

1шт.

D44110

OPEN END WRENCH

SET - spanner wrench (For removing and installing packing gland in threaded gland type hydraulic cylinders)

1шт.

2

D44111

OPEN END WRENCH

WRENCH - spanner, for 2-1/2" I.D. cylinder with 1-1/4" or 1-1/2" piston rods, Includes: Ref. 3 and 4

1шт.

D44112

OPEN END WRENCH

WRENCH - spanner, for 3" I.D. cylinders with 1-1/2" piston rod, Includes: Ref. 3 and 4

1шт.

D44113

OPEN END WRENCH

WRENCH - spanner, for 3" I.D. cylinder with 1-3/4" piston rod, Includes: Ref. 3 and 4

1шт.

D44114

OPEN END WRENCH

WRENCH - spanner, for 3-1/2" I.D. cylinders with 1-3/4" or 2" piston rods, Includes: Ref. 3 and 4

1шт.

G33234

OPEN END WRENCH

WRENCH - spanner, for 4" I.D. cylinders with 2" or 2-1/4" piston rods, Includes: Ref. 3 and 4

1шт.

G33235

OPEN END WRENCH

WRENCH - spanner, for 4-1/2" I.D. cylinders with 2-1/2" piston rod, Includes: Ref. 3 and 4

1шт.

3

D30107

PIN

- spanner wrench, for 2-1/2" I.D. thru 4" I.D. cylinders

3шт.

4

D44118

SPARE PART

PIN - spanner wrench, for 4-1/2" I.D. cylinders

3шт.

5

321-2102

DECAL

- check oil level, on R.H. loader frame

1шт.

Part of P/N L45504 Decal Kit

1шт.

6

321-663

DECAL

- patent, on L.H. loader frame

1шт.

Part of P/N L45504 Decal Kit

1шт.

7

321-230

DECAL

- diesel fuel, on fuel tank

1шт.

Part of P/N L45504 Decal Kit

1шт.

7

321-18

DECAL

- gasoline (Not shown) on fuel tank

1шт.

Part of P/N L45504 Decal Kit

1шт.

8

321-994

DECAL

- 480, on each side of hood

2шт.

9

321-996

DECAL

- CASE, R.H. hood (If used)

1шт.

9

321-997

DECAL

- CASE, L.H. hood (Not shown) if used

1шт.

9a

321-1566

DECAL

- CASE, R.H. hood (If used)

1шт.

Part of P/N L45504 Decal Kit

1шт.

9a

321-1567

DECAL

- CASE, L.H. hood (Not shown) if used

1шт.

Part of P/N L45504 Decal Kit

1шт.

10

321-3061

DECAL

- warning, pressure cap (On radiator)

1шт.

11

321-1030

DECAL

- shifting (Dual range) L.H. side of dash

1шт.

Part of P/N L45504 Decal Kit

1шт.

12

321-948

DECAL

- shifting (4 speed) L.H. side of dash

1шт.

Part of P/N L45504 Decal Kit

1шт.

14

321-666

DECAL

- starting, gas models (R.H. side of dash)

1шт.

15

321-662

DECAL

- warning, lower or block hydraulically (At loader controls)

1шт.

Part of P/N L45504 Decal Kit

1шт.

16

321-229

DECAL

- hydraulic fluid, on R.H. loader frame

1шт.

Part of P/N L45504 Decal Kit

1шт.

17

321-1230

DECAL

- control valve, on loader controls

1шт.

Part of P/N L45504 Decal Kit

1шт.

18

321-1003

DECAL

- CK, loader lift frame (If used)

2шт.

19

321-1482

DECAL

- CK, on loader lift frame (If used)

2шт.

Part of P/N L45504 Decal Kit

1шт.

20

321-1010

DECAL

- CASE, on loader lift frame (If used)

2шт.

21

321-1438

DECAL

- CASE, on side of hood (If used)

2шт.

Part of P/N L45504 Decal Kit

1шт.

22

321-3050

DECAL

- warning, do not roll back bucket (At loader controls)

1шт.

23

321-1570

DECAL

- CASE, loader models (Reflective) back of operators seat (When stock is exhausted, order 321-1334 decal for service)

1шт.

23

321-1334

DECAL

- CASE, loader models (Non reflective) back of operators seat

1шт.

24

321-2101

DECAL

- oil filter

1шт.

25

321-246

DECAL

- patent, tractor

1шт.

L45504

KIT

decal, Includes: Refs. 5 -7, 9A, 11, 12, 15 - 17, 19 and 21

1шт.

Выбрано товаров: 49
