(88.050.01[03]) - DIA KIT, A/C HPCR

Запчасти Case 590SN (88.050.01[03]) - DIA KIT, A/C HPCR (88) - ACCESSORIES

Схема запчастей Case 590SN - (88.050.01[03]) - DIA KIT, A/C HPCR (88) - ACCESSORIES
1
4
3
50.200.0202
home
39.100.02
2
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84412148

SERVICE KIT

A/C HPCR, Incl 2 - 4, Serial Range: -`0

1шт.

See Ref. 88.050.01 [01] to 88.050.01 [02], 88.050.01 [04] to 88.050.01 [05]

1шт.

Refer to Installation Instructions for Correct Assembly Procedure

1шт.

2

87546291

CONDENSER

1шт.

3

87606977

BRACKET, PIVOT

1шт.

4

87606979

BRACKET

1шт.

Выбрано товаров: 6
