(88.035.40[11]) - DIA KIT, NO AUX TO COMBO, STANDARD, PILOT CONTROLS

Запчасти Case 590SN (88.035.40[11]) - DIA KIT, NO AUX TO COMBO, STANDARD, PILOT CONTROLS (88) - ACCESSORIES

Схема запчастей Case 590SN - (88.035.40[11]) - DIA KIT, NO AUX TO COMBO, STANDARD, PILOT CONTROLS (88) - ACCESSORIES
3
1
39.100.0202
35.726.5601 01
2
home
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

47360534

CONSTRUCTION DIA

NO AUX TO COMBO, STANDARD, PILOT CONTROLS, Incl 2 - 3

1шт.

See Ref. 88.035.40 [01] to 88.035.40 [10]

1шт.

Refer to Installation Instructions for Correct Assembly Procedure

1шт.

2

84258266

HOSE ASSY.,19mm ID x 713mm L

1шт.

3

84292024

HYD TUBE

1шт.
