Запчасти Case 590SN (88.035.28[02]) - DIA KIT, LOADER CONTROL VALVE, 3 SECTIONS - BUCKET SECTION, CLAM CYLINDER (PILOT CONTROLS) (88) - ACCESSORIES
![Схема запчастей Case 590SN - (88.035.28[02]) - DIA KIT, LOADER CONTROL VALVE, 3 SECTIONS - BUCKET SECTION, CLAM CYLINDER (PILOT CONTROLS) (88) - ACCESSORIES](https://partsell.ru/storage/images/casece/3755423.png)
3
2
6
4
5
3
1
8
5
4
3
7
home
6
№
Артикул
Название
Примечание
Количество
1
84484676
SERVICE KIT
Loader Control Valve, 3 Sections, Bucket Section, Clam Cylinder (Pilot Controls), Incl 2 - 8, Serial Range: -`0
1шт.
See Ref. 88.035.28 [01]
1шт.
2
84157590
COMPENSATOR
1шт.
3
87346914
KIT
1шт.
4
84232746
PLUG
2шт.
5
85825473
SEAL KIT
1шт.
6
87617657
O-RING KIT
1шт.
7
NSS
NOT SOLD SEPARAT
Valve, Incl in 8
1шт.
8
84295102
HYD VALVE SECTION
Assy, Incl 2 - 7
1шт.
Выбрано товаров: 9
