Запчасти Case 590SN (88.035.26[03]) - DIA KIT, HYDRAULIC LOADER COUPLER SYSTEM (88) - ACCESSORIES

Схема запчастей Case 590SN - (88.035.26[03]) - DIA KIT, HYDRAULIC LOADER COUPLER SYSTEM (88) - ACCESSORIES
5
7
5
1
8
6
3
5
home
4
3
2
3
5
2

Артикул

Название

Примечание

Количество

1

84492774

KIT

Hydraulic Loader Coupler System, Incl 2 - 8, Serial Range: -`0

1шт.

Refer to Installation Instructions for Correct Assembly Procedure,See Ref. 88.035.26 [01] to 88.035.26 [02], 88.035.26 [04] to 88.035.26 [06]

1шт.

2

87438021

SOLENOID VALVE

Assy, Incl 3

2шт.

3

87438024

SEAL KIT

1шт.

4

87438025

SOLENOID VALVE

Assy, Incl 5

1шт.

5

87438028

SEAL KIT

1шт.

6

87438029

VALVE, CHECK

Assy, Incl 5

1шт.

7

84200896

VALVE PRESSURE RELIE

Assy, Incl 5

1шт.

8

87435910

SOLENOID VALVE

Assy, Incl 2 - 7

1шт.

Выбрано товаров: 9
