Запчасти Case 590SN (88.035.26[01]) - DIA KIT, HYDRAULIC LOADER COUPLER SYSTEM (88) - ACCESSORIES

1

84492774

KIT

Hydraulic Loader Coupler System, Incl 2 - 16, Serial Range: -`0

1шт.

Refer to Installation Instructions for Correct Assembly Procedure,See Ref. 88.035.26 [02] to 88.035.26 [06]

1шт.

2

84492775

INSTRUCTION

1шт.

3

84367364

LOADER

1шт.

4

84266292

HYDRAULIC HOSE,6.35mm ID x 740mm L, SAE 100R16

2шт.

5

84311873

HOSE,6.35mm ID x 1497mm L, SAE 100R16

1шт.

6

84337930

HOSE,6.35mm ID x 1497mm L, SAE 100R16

1шт.

7

84346489

PLATE

1шт.

8

84401877

HYD TUBE

1шт.

9

84401879

HYD TUBE

1шт.

10

86566989

CABLE TIE,208mm L

5шт.

11

120303A1

SPACER,11mm ID x 15.82mm OD x 15mm Thk

1шт.

12

302820A2

CLAMP

3шт.

13

D138055

CLAMP

3шт.

14

L11541

CABLE TIE,203.2mm L, Nylon

1шт.

15

120073

BOLT,Hex, M10 x 86.58mm, Cl 8.8

1шт.

16

412141

NUT,M10 x 1.5, Cl 8

1шт.
