Запчасти Case 590SN (88.035.20[03]) - DIA KIT, DUAL-AUX, PILOT CONTROLS, EXTENDABLE DIPPER (88) - ACCESSORIES

Схема запчастей Case 590SN - (88.035.20[03]) - DIA KIT, DUAL-AUX, PILOT CONTROLS, EXTENDABLE DIPPER (88) - ACCESSORIES
1
4
2
35.726.52
35.726.52
35.726.52
home
35.726.52
3

Артикул

Название

Примечание

Количество

1

84492791

SERVICE KIT

Dual-Aux, Pilot Controls, Extendable Dipper, Incl 2 - 4, Serial Range: -`0

1шт.

See Ref. 88.035.20 [01] to 88.035.20 [02]

1шт.

2

225353C1

WEDGE,Lock, Black

Type W6P, Connector

1шт.

3

84134639

SWITCH

Push Button; Retract and Extendahoe

2шт.

4

225350C1

ELEC CONNECTOR,Male, 6 Pin

1шт.

Выбрано товаров: 5
