Запчасти Case 590SN (55.513.14) - HARNESS INSTALL - SIDE CONSOLE, S AND H TYPE TRANSMISSION (55) - ELECTRICAL SYSTEMS

1

515-23444

CLAMP,1 3/4", Insul, 3/8" Bolt

1шт.

2

614-8030

BOLT,Hex, M8 x 1.25 x 30mm, Cl 8.8, Full Thd

1шт.

3

892-11008

LOCK WASHER,8mm ID

1шт.

4

824-1408

NUT,M8 x 1.25, Cl 10

1шт.

5

844-6025

BOLT,Hvy Hex, M6 x 25mm, Cl 8.8

2шт.

6

832-10406

NUT,M6 x 1, Cl 8

2шт.

7

87655042

SPECIAL WASHER,8.8mm ID x 17.5mm OD x 2.2mm Thk

1шт.

8

844-10020

BOLT,Hvy Hex, M10 x 20mm, Cl 8.8

1шт.

9

L11541

CABLE TIE,203.2mm L, Nylon

CABLE STRAP

1шт.
