(35.726.56[07]) - VALVE - BACKHOE, BUCKET (WITH PILOT CONTROLS)

Запчасти Case 590SN (35.726.56[07]) - VALVE - BACKHOE, BUCKET (WITH PILOT CONTROLS) (35) - HYDRAULIC SYSTEMS

Схема запчастей Case 590SN - (35.726.56[07]) - VALVE - BACKHOE, BUCKET (WITH PILOT CONTROLS) (35) - HYDRAULIC SYSTEMS
5
4
1
home
2
5
6
4
3
3
6
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84278702

HYD VALVE SECTION

Assy, Incl 2 - 6

1шт.

2

84157590

COMPENSATOR

1шт.

3

85826344

KIT,Operation

1шт.

4

85825473

SEAL KIT

1шт.

5

84295049

VALVE PRESSURE RELIE,283 Bar

1шт.

5

84295050

VALVE PRESSURE RELIE,296 Bar

1шт.

6

87617657

O-RING KIT

1шт.
