(35.726.56[04]) - VALVE - BACKHOE, BOOM (WITH PILOT CONTROLS)

Запчасти Case 590SN (35.726.56[04]) - VALVE - BACKHOE, BOOM (WITH PILOT CONTROLS) (35) - HYDRAULIC SYSTEMS

Схема запчастей Case 590SN - (35.726.56[04]) - VALVE - BACKHOE, BOOM (WITH PILOT CONTROLS) (35) - HYDRAULIC SYSTEMS
6
3
5
1
4
6
home
3
4
2
5
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84278714

HYD VALVE SECTION

Assy, Incl 2 - 6

1шт.

1

84278714R

REMAN-HYD VALVE

Reman Assy, Incl 2 - 6

1шт.

1

84278714C

CORE-VALVE HYD

Core Return Number

1шт.

2

84157590

COMPENSATOR

1шт.

3

85826344

KIT,Operation

1шт.

4

85825473

SEAL KIT

1шт.

5

84295045

VALVE PRESSURE RELIE,340 Bar

1шт.

5

84295048

VALVE PRESSURE RELIE,230 Bar

1шт.

6

87617657

O-RING KIT

1шт.
