Артикул
Название
Примечание
Количество
1
84989848
TEE,11/16" - 16 ORFS x 11/16" - 16 ORFS x 11/16" - 16 JIC
Assy, Incl 2
2шт.
3
84523981
HYDRAULIC HOSE,9.53mm ID x 550mm L, SAE 100R16
1шт.
4
143219A1
HOSE PROTECTION,19mm ID x 24mm OD x 450mm L
1шт.
5
84275042
HOSE ASSY.,19mm ID x 411mm L
1шт.
6
9706702
BOLT,Hex, M12 x 1.75 x 50mm, Cl 8.8
2шт.
7
87655043
WASHER,M12, 13.65mm ID x 24.90mm OD x 3.20mm, HT Boron, ZNM
4шт.
8
9840535
HYD CONNECTOR,1-3/16" - 12 ORFS x 1-1/16" - 12 ORB
Assy, Incl 9 - 10
1шт.
9
167266
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
1шт.
11
84257782
BRACKET
1шт.
13
76349
PLUG,9/16" - 18 ORB
Assy, Incl 14
1шт.
15
337475
NUT,M12, Cl 10
2шт.
17
9846956
90 ELBOW,90 Degree, 1-7/16"-12 x 1-1/16"-12, Adj, ORFS
Assy, Incl 9, 18
1шт.
19
86639084
BHD LOCK NUT,1-7/16"-12, ORFS, Bulkhead
2шт.
21
84407250
BRACKET, SUPPORTING
1шт.
22
86639060
UNION,1-7/16"-12 ORFS, Bulkhead
2шт.
23
3416158
O-RING,0.07" Thk x 0.301" ID, -11, Cl 5, 75 Duro
2шт.
25
84407248
HYD TUBE
Assy, Incl 26
1шт.
26
86639097
TUBE NUT,1-7/16"-12
1шт.
27
120303A1
SPACER,11mm ID x 15.82mm OD x 15mm Thk
1шт.
28
814-8040
BOLT,Hex, M8 x 1.25 x 40mm, Cl 8.8
1шт.
29
86637996
CLAMP,28.6mm, Coat, 10.3mm Bolt Hole, P Type
1шт.
30
832-10408
NUT,M8 x 1.25, Cl 8.8
1шт.
31
87655042
SPECIAL WASHER,8.8mm ID x 17.5mm OD x 2.2mm Thk
1шт.
32
84407245
HYDRAULIC HOSE,19mm ID x 953mm L
1шт.
33
84989413
ELBOW,90 Degree, 1 7/16"-12 ORFS x 1 7/16"-12 Fem Sw
Assy, Incl 18
1шт.
34
84259313
FITTING,1"7/16 - 12 ORFS x 1"5/16 - 12 ORB
1шт.
35
84259315
HOSE ASSY.,10mm ID x 288mm L
1шт.
37
1960667
HEX SOC SCREW,M8 x 90mm, Cl 8.8
2шт.
Выбрано товаров: 37
