Запчасти Case 590SN (39.105.09) - BACKHOE - BOOM AND SWING TOWER (590SN) (39) - FRAMES AND BALLASTING

1

84304072

TOWER

Swing

1шт.

2

84246814

SPECIAL WASHER,82mm ID x 144mm OD x 1.10mm Thk

1шт.

3

84238031

BOOM

15 Foot

1шт.

4

84230831

PIN,80mm OD x 115mm L

Boom To Tower

2шт.

5

84230833

PIN,70mm OD x 310.1mm L

Cylinders To Boom

1шт.

6

800-40070

SNAP RING,M70 Ext

6шт.

7

D136391

SHIM,72mm ID x 89mm OD x 1.57mm Thk

3шт.

8

D136392

SHIM,72mm ID x 89mm OD x 3.05mm Thk

3шт.

9

84230834

PIN

Boom To Dipper

1шт.

10

122897A1

SPACER,21mm ID x 31.75mm OD x 12mm L

1шт.

11

84230833

PIN,70mm OD x 310.1mm L

1шт.

12

604-20040

BOLT,Hex, M20 x 40mm, Cl 8.8

1шт.

13

84246323

RETAINER,18mm ID

Boom To Tower Pin

2шт.

14

87655044

SPECIAL WASHER,17.75mm ID x 31.50mm OD x 4.20mm, HTS Boron, ZNM

2шт.

15

84246776

PREV TORQUE BOLT,Hex, M16 x 35mm, Cl 10.9

2шт.

16

84230833

PIN,70mm OD x 310.1mm L

Cylinders To Boom

1шт.

17

84245639

BUMPER

1шт.

18

84246817

PIN,79.9mm OD x 192mm L

Upper Tower

1шт.

19

D144485

SHIM,82mm ID x 98mm OD x 3.05mm Thk

4шт.

20

D144486

SHIM,82mm ID x 98mm OD x 1.57mm Thk

6шт.

21

84246816

PIN,75.7mm Dia x 173mm L

Lower Tower

1шт.

22

84247078

PIN,80mm Dia x 162.5mm L

Boom Cylinder To Tower

1шт.

23

800-40080

SNAP RING,M80, Ext

6шт.

24

711-10040

CARRIAGE BOLT,Short NK, M10 x 40, Cl8.8, Full Thd

1шт.

25

832-10410

NUT,M10 x 1.5, Cl 8

1шт.

26

219-1

LUBE NIPPLE,1/8" - 27 NPTF

5шт.

27

219-55

LUBE NIPPLE,90 Degree Elbow, 1/8" - 27 NPTF

1шт.

28

84249358

PIN

Swing Lock

1шт.

29

84261891

SHIM,82mm ID x 140mm OD x 3mm Thk

3.00mm Thk; Swing Tower

3шт.

30

84261890

SHIM,82mm ID x 140mm OD x 2mm Thk

2.00mm Thk; Swing Tower

2шт.

31

84261887

PIN,50.77mm OD x 146.7mm L

Swing Cylinder Eye

2шт.

32

495-81227

WASHER,52.38mm ID x 74.63mm OD x 1.7mm Thk

2шт.

33

103-16200

SNAP RING,#200, Ext

2шт.

34

84265979

SPECIAL WASHER,13mm ID x 60mm OD x 3mm Thk

Pin Retainer

2шт.

35

86566268

LOCK BOLT,Prev Torque, Hex, M12 x 1.75 x 35mm, Cl 8.8, Full Thd

2шт.

84230835

PIN,70mm OD x 192.1mm L

Not Illustrated - Dipper Cylinder Open End to Dipper

1шт.
