Запчасти Case 590SN (35.724.17[05]) - VAR - 747864, X20137X - LOADER CONTROL VALVE, 3 SECTIONS - BUCKET SECTION, CLAM CYLINDER (PILOT CONTROLS) (35) - HYDRAULIC SYSTEMS

Схема запчастей Case 590SN - (35.724.17[05]) - VAR - 747864, X20137X - LOADER CONTROL VALVE, 3 SECTIONS - BUCKET SECTION, CLAM CYLINDER (PILOT CONTROLS) (35) - HYDRAULIC SYSTEMS
5
5
3
4
5
6
1
4
6
home

Артикул

Название

Примечание

Количество

1

84295102

HYD VALVE SECTION

Assy, Incl 2 - 6

1шт.

2

84157590

COMPENSATOR

1шт.

3

87346914

KIT

1шт.

4

84232746

PLUG

2шт.

5

85825473

SEAL KIT

1шт.

6

87617657

O-RING KIT

1шт.

Выбрано товаров: 6
