Запчасти Case 590SN (84.912.AD[04]) - VAR - 423076 - EXTENDABLE DIPPER, BUSHING (84) - BOOMS, DIPPERS & BUCKETS

1

84229926

BUSHING,70.19mm ID x 79.98mm OD x 34mm L

70.19mm ID x 79.98mm OD x 34mm L

2шт.

2

84234854

BUSHING,80.19mm ID x 99.98mm OD x 50mm L

80.19mm ID x 99.98mm OD x 50mm L

2шт.

3

47520387

CONSTRUCTION DIA

Convert Standard Dipper to Extendable Dipper, Foot Swing Control, Incl 1, 2

1шт.

To See Full DIA KIT Composition Look for all the Figures Where the DIA KIT P/N Is Shown

1шт.

3

47520393

CONSTRUCTION DIA

Convert Standard Dipper to Extendable Dipper, Hand Swing Control, Incl 1, 2

1шт.

To See Full DIA KIT Composition Look for all the Figures Where the DIA KIT P/N Is Shown

1шт.
