(35.355.AK[03]) - VAR - 742369 - BACKHOE ARM, MECHANICAL, CONTROL LEVER, HAND SWING

Запчасти Case 590SN (35.355.AK[03]) - VAR - 742369 - BACKHOE ARM, MECHANICAL, CONTROL LEVER, HAND SWING (35) - HYDRAULIC SYSTEMS

Схема запчастей Case 590SN - (35.355.AK[03]) - VAR - 742369 - BACKHOE ARM, MECHANICAL, CONTROL LEVER, HAND SWING (35) - HYDRAULIC SYSTEMS
35.355.ak (02)
5
5
6
1
4
3
6
2
4
3
4
5
6
8
7
35.359.ab (07)
35.359.ab (05)
35.359.af (01)
35.359.ab (01)
35.359.ab (02)
35.359.ab (03)
35.359.ab (06)
35.359.ab (04)
35.359.ab (08)
35.359.af (03)
35.359.af (02)
35.359.af (04)
35.355.ak (01)
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

390758A1

COVER

Rear Backhoe Console 2 Lever

1шт.

2

136824A1

LARGE PLATE

Boot Retaining 2 Lever

1шт.

3

87310126

SCREW,Phillips Drive, Pan HD, #10 - 24 x 3/4", SST

6шт.

4

131-861

SPRING NUT,Tinn, U, #10-24

6шт.

5

87310156

SELF-TAP SCREW,M6.3 x 1.8 x 16mm, Stainless

5шт.

6

87310139

WASHER,7.14mm ID x 15.88mm OD x 1.65mm Thk

5шт.

7

353-411

PLUG,Dome, 1.000" hole, Nylon

1шт.

8

47453063

CONSTRUCTION DIA

Convert Foot Swing to 2 Lever, Standard Dipper, Incl 1 - 7

1шт.

To See Full DIA KIT Composition Look for all the Figures Where the DIA KIT P/N Is Shown

1шт.

8

47453065

CONSTRUCTION DIA

Convert Foot Swing to 2 Lever, Extendable Dipper, Incl 1 - 7

1шт.

To See Full DIA KIT Composition Look for all the Figures Where the DIA KIT P/N Is Shown

1шт.
