(90.108.01[02]) - VAR - 423056, 747882, 747883, X47086X - DECALS

Запчасти Case 580SN WT (90.108.01[02]) - VAR - 423056, 747882, 747883, X47086X - DECALS (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case 580SN WT - (90.108.01[02]) - VAR - 423056, 747882, 747883, X47086X - DECALS (90) - PLATFORM, CAB, BODYWORK AND DECALS
14
13
8
4
home
1
3
10
6
9
12
11
5
2
7
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84237467

DECAL

Two Function Loader Control

1шт.

2

84237478

DECAL

Three Function Loader Control

1шт.

3

D149824

DECAL

Backhoe Control

1шт.

4

D149825

DECAL

Extendahoe Control

1шт.

5

D149828

DECAL

Upper; Standard Backhoe Control Pattern; With Hand Swing; Left Hand Side Of Console

1шт.

6

D149829

DECAL

Upper; Standard Backhoe Control Pattern; With Hand Swing; Right Hand Side Of Console

1шт.

7

449842A1

REFLECTOR,160mm x 50.8mm H - Red

2x6-5/16 in; Red Reflector

1шт.

8

192450A1

DECAL

Clear Vinyl; Hood

1шт.

9

D55216

PAD,2" x 9"

NON-SLIP, 2x9 in

1шт.

10

D80270

ANTI-SKID STRIP,635mm / 25 Inch

635 mm (25 in); Canopy

1шт.

11

87694065

ANTI-SKID STRIP

676 mm (26.61 in); Toolbox

1шт.

12

367848A2

PAD

Anti-Skid; Canopy Models

1шт.

13

T41159

TAPE,82mm x 35mm H

Adhesive Strip

2шт.

14

406723A1

DECAL

Poly film; Lockup Cover; Canopy Models

1шт.
