Запчасти Case 580SN WT (90.100.10) - INSTRUMENT PANEL, SIDE - COVERS (RIGHT-HAND SIDE) (90) - PLATFORM, CAB, BODYWORK AND DECALS

1

390255A2

BEZEL

Cab

1шт.

2

391818A2

BEZEL

Canopy

1шт.

3

87310098

BOLT,M6 x 20 Full SST BLO

1шт.

4

87310152

BOLT,M6 x 16 Full SST BLO

11шт.

5

84328907

CONSOLE

9шт.

6

355198A2

CONSOLE

Single-Door Cab

1шт.

6

366633A3

LID

Console Lid (Not Shown)

1шт.

7

360250A2

CONSOLE

Canopy

1шт.

8

372167A1

CONSOLE

2-Door Cab

1шт.

9

87406924

REAR VIEW MIRROR

1шт.

10

131-861

SPRING NUT,Tinn, U, #10-24

4шт.

11

231-14109

LOCK NUT,#10-24, GB

2шт.

12

832-10404

NUT,M4 x 0.7, Cl 8.8

4шт.

13

833-40406

NUT,M6, U

18шт.

14

131-619

SPRING NUT,J, #10 - 24, 0.031" Thk

2шт.

15

127009A1

CLIP,ELECTRICAL

3шт.

16

87310126

SCREW,Phillips Drive, Pan HD, #10 - 24 x 3/4", SST

4шт.

17

87310127

SCREW,Pan HD, #10 - 24 x 1", SST

2шт.

18

87310128

SCREW,Pan Cross Recess Phillips, #10 - 24 x 57.20mm, Stainless

2шт.

19

286-56520

SELF-TAP SCREW,Cross Fil Hd, #10-24 x 1 1/4"

2шт.

20

87310184

SCREW,Phillips Drive, Oval HD, M4 x 0.7 x 16mm, SST

4шт.

21

L60224

BUMPER

1шт.

22

184726A1

FIXING STRIP

Fire Extinguisher Retaining Strap

1шт.

23

182594A1

HANDLE

2шт.

24

87310146

WASHER,5.16mm ID x 19.05mm OD x 1.55mm Thk

4шт.

25

895-11004

WASHER,4.3mm ID x 9mm OD x 0.8mm Thk

4шт.

26

84328909

COVER

Fuse Panel

1шт.

27

414071A1

SEALING STRIP,480mm

1шт.

28

353-411

PLUG,Dome, 1.000" hole, Nylon

1шт.

29

87399709

THUMB SCREW,Knurled, 10-24 x 1/2" L

2шт.

30

131-121

SPRING NUT,Tinn, U, #10-24

1шт.
