Запчасти Case 580SN WT (82.100.01[01]) - BUCKET, LOADER LONG LIP (93 IN) (82) - FRONT LOADER & BUCKET

1

84235066

BUCKET

1шт.

2

86625260

WASHER,21.8mm ID x 37.5mm OD x 4mm Thk

4шт.

3

412180

NUT,M20 x 2.5, Cl 8

2шт.

4

84235628

SPACER,21mm ID x 25mm OD x 100mm L

2шт.

5

84334022

BOLT,Hex, M20 x 2.5 x 180mm, Cl 10.9

2шт.

6

185506A1

CUTTING EDGE

Replaces 87375240 Unpainted Cutting Edge

1шт.

7

20-21232

PLOW BOLT,#3, 3/4" - 10 x 2", Gr 8

10шт.

8

29-1012

NUT,3/4"-10, G8

10шт.

9

D129264

BUSHING,40.3mm ID x 50mm OD x 28mm L

Not Shown

8шт.
