1
2854594
ECU
1шт.
1
2854594R
REMAN-MODULE
Remanufactured Electronic Control Unit
1шт.
1
2854594C
CORE-MODULE
CORE-MODUL Return Number, ELECTRONIC CONTROL UNIT
1шт.
2854595
BRACKET
Incl. Refs. 2 - 7
1шт.
2
2854596
BRACKET
Support, Electronic Unit
1шт.
3
2854079
GASKET,6.45mm Thk
1шт.
4
4896542
HYD CONNECTOR,M12 x 1.5 ORB x 6 ORFS
M12 x 1.5
1шт.
5
2854292
SEALING WASHER,12mm ID x 17mm OD x 1.5mm Thk
SEAL WASHER
2шт.
6
2855150
INSULATOR BLOCK
Stop
6шт.
7
4890964
FITTING,M12 x 1.5
1шт.
8
4899078
SCREW,Hex Flg, M8 x 1.25 x 45
3шт.
9
2854593
STUD
1шт.
10
4899057
FLANGE NUT,M6
1шт.
11
2852825
PLUG,100mm x 40mm L
1шт.
12
2852818
SCREW,Hex, M6 x 1 x 30mm
M6 x 30
7шт.
13
2852486
CABLE CLIP
2шт.
14
2854282
NUT,M6 x 1
Hex, M6 x 1
1шт.
15
4899124
WASHER
1шт.
16
4895157
STUD
1шт.
17
4890190
SENSOR
Camshaft Position/Speed; Incl. Ref. 17A
1шт.
17a
2852820
O-RING,0.07" Thk x 0.676" ID, 17, Cl 7, 75 Duro
17.17 x 1.78 mm
1шт.
18
4892255
HOUSING
Sender Unit
1шт.
19
14453881
O-RING,23.52mm ID x 1.78" Width
1шт.
20
4899110
SCREW,Hex Flg, M6 x 1 x 20
3шт.
21
4890193
SENSOR
Oil Pressure & Temp. Incl. Ref, 21A
1шт.
21a
4895477
O-RING,2.62mm Thk x 13.94mm ID
1шт.
22
4890189
SENSOR
Crankshaft Position/Speed
1шт.
23
4897224
SENSOR
Temperature, Two Wire
1шт.
23a
A166057
TEMPERATURE SENDER,1/2" - 14 NPTF
One wire (Not shown)
1шт.
24
2852821
SENSOR
ECM; Boost/Air Temperature
1шт.
25
4895817
BOLT,Flng, M6 x 1 x 20mm, Cl 10.9
1шт.
