Запчасти Case 580SN WT (35.738.04[01]) - CYLINDER - BACKHOE BUCKET (580SN, 580SN WT) (35) - HYDRAULIC SYSTEMS

1

84210935

HYDRAULIC CYLINDER,Double Acting, 63.5mm Rod, 897.9mm Stroke

1шт.

1

84210935R

REMAN-HYD CYLINDER

580SN 58SN01, 580SN WT BOTH TIER 3

1шт.

1

84210935C

CORE-HYD CYLINDER

RETURN NUMBER

1шт.

2

84233448

BARREL,88.75mm Bore Dia

1шт.

3

84323183

ROD,63.5mm OD

Incl 18

1шт.

4

86982442

SPECIAL BOLT,Hex, 12, 1 1/4 x 3.25"

1шт.

5

G109395

SELF-TAP SCREW,Hex, #8 - 32 x 3/8"

2шт.

6

219-1

LUBE NIPPLE,1/8" - 27 NPTF

2шт.

7

353-782

PLUG,Slotted, 1 1/16"-12

1шт.

8

84232661

PISTON ROD/GLAND,87.41mm Bore, 63.5mm Rod, 74.65mm W

1шт.

9

G100711

SEAL,Split, 82.55mm ID x 88.9mm OD x 9.52mm Thk

1шт.

10

238799A1

SEALING RING,Locking, 80.65mm ID x 88.77mm OD x 4.74mm Thk

1шт.

11

87715783

SEAL,76.45mm ID x 88.9mm OD

1шт.

12

D95146

WIPER SEAL,63.4mm ID x 76.22mm OD x 7.92mm Thk

1шт.

13

84130482

SEAL,81.4mm ID x 88.56mm OD x 4.85mm Thk

1шт.

14

84190554

GLAND

Inc. 12,13,15,16

1шт.

15

G109908

BUSHING,63.5mm ID x 66.57mm OD x 25.15mm L

1шт.

16

1542879C1

SEAL KIT,63.5mm Rod x 88.9mm Bore

Rod and Buffer

1шт.

17

84259225

SEAL KIT,63.5mm Rod x 88.9mm Bore

(Not Shown)

1шт.

18

123407A1

BUSHING,60.19mm ID x 70mm OD x 28mm L

Incl in 3

2шт.
