(35.724.17) - VALVE SECTION - BUCKET, LOADER (PILOT CONTROLS) (580SN, 580SN WT, 590SN)

Запчасти Case 580SN WT (35.724.17) - VALVE SECTION - BUCKET, LOADER (PILOT CONTROLS) (580SN, 580SN WT, 590SN) (35) - HYDRAULIC SYSTEMS

Схема запчастей Case 580SN WT - (35.724.17) - VALVE SECTION - BUCKET, LOADER (PILOT CONTROLS) (580SN, 580SN WT, 590SN) (35) - HYDRAULIC SYSTEMS
5
3
6
home
2
9
1
8
7
4
7
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84295100

HYD VALVE SECTION

Loader Bucket

1шт.

2

84157590

COMPENSATOR

1шт.

3

85824278

KIT

1шт.

4

85820130

BOOT

1шт.

5

87754355

SERVICE KIT

1шт.

6

87754413

SERVICE KIT

1шт.

7

84295052

VALVE PRESSURE RELIE

2шт.

8

85825473

SEAL KIT

1шт.

9

87617657

O-RING KIT

1шт.

Выбрано товаров: 9
