(35.150.11) - VALVE SECTION - BACKHOE, EXTENDABLE BOOM (WITH PILOT CONTROLS)

Запчасти Case 580SN WT (35.150.11) - VALVE SECTION - BACKHOE, EXTENDABLE BOOM (WITH PILOT CONTROLS) (35) - HYDRAULIC SYSTEMS

Схема запчастей Case 580SN WT - (35.150.11) - VALVE SECTION - BACKHOE, EXTENDABLE BOOM (WITH PILOT CONTROLS) (35) - HYDRAULIC SYSTEMS
3
home
2
6
4
1
6
5
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84278692

HYD VALVE SECTION

Extendable dipper

1шт.

2

85826344

KIT,Operation

1шт.

3

87617657

O-RING KIT

1шт.

4

84157590

COMPENSATOR

1шт.

5

85825473

SEAL KIT

1шт.

6

84232746

PLUG

2шт.

Выбрано товаров: 0
