(35.150.03) - VALVE SECTION - BACKHOE, BUCKET (WITH PILOT CONTROLS)

Запчасти Case 580SN WT (35.150.03) - VALVE SECTION - BACKHOE, BUCKET (WITH PILOT CONTROLS) (35) - HYDRAULIC SYSTEMS

Схема запчастей Case 580SN WT - (35.150.03) - VALVE SECTION - BACKHOE, BUCKET (WITH PILOT CONTROLS) (35) - HYDRAULIC SYSTEMS
4
home
6
1
3
2
5
5
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84278702

HYD VALVE SECTION

Bucket

1шт.

2

84157590

COMPENSATOR

1шт.

3

85826344

KIT,Operation

1шт.

4

85825473

SEAL KIT

1шт.

5

84295049

VALVE PRESSURE RELIE,283 Bar

283 BAR

1шт.

5

84295050

VALVE PRESSURE RELIE,296 Bar

296 BAR

1шт.

6

87617657

O-RING KIT

1шт.

Выбрано товаров: 7
