Запчасти Case 580SN WT (44.100.17[02]) - AXLE, FRONT - HOUSING, SWIVEL (580SN WT, 590SN) (25) - FRONT AXLE SYSTEM

Схема запчастей Case 580SN WT - (44.100.17[02]) - AXLE, FRONT - HOUSING, SWIVEL (580SN WT, 590SN) (25) - FRONT AXLE SYSTEM
3
6
5
1
home
4
5
2
7

Артикул

Название

Примечание

Количество

1

84259616

STEERING KNUCKLE

Left Hand

1шт.

1

84259618

STEERING KNUCKLE

Right Hand (Not Shown)

1шт.

2

84259754

PIN,49.9mm OD x 48mm L

2шт.

3

84259753

PIN,49.9mm OD x 45mm L

2шт.

4

84351730

FITTING,M10 x 1

1шт.

5

84273749

BOLT,M14 x 2 x 35mm

6шт.

6

87751873

SCREW,M18 x 105mm, Cl 10.9

1шт.

7

10717624

THIN NUT,Thin, M18 x 2.5, Cl 05

1шт.

Выбрано товаров: 8
