Запчасти Case 580SN WT (35.738.AE[01]) - VAR - 423075 - BACKHOE BUCKET, STANDARD DIPPER, CYLINDER, LINES (35) - HYDRAULIC SYSTEMS

1

84281616

HOSE ASSY.,15.88mm ID x 2800mm L, SAE 100R16

Valve to Bucket, Incl 2, 3 (Qty 1)

1шт.

2

NSS

NOT SOLD SEPARAT

Hose, Incl in 1

1шт.

3

9991976

O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro

4шт.

4

84257611

HYDRAULIC HOSE,15.88mm ID x 2755mm L, SAE 100R16

ASSY, Valve to Bucket, Incl 3 (Qty 1), 5

1шт.

5

NSS

NOT SOLD SEPARAT

Hose, Incl in 4

1шт.

6

84399338

HYDRAULIC HOSE,16mm ID x 1252mm L

Bucket Head

1шт.

7

84305540

TUBE

ASSY, Bucket Cylinder Rod, 985mm L, Incl 8, 9 (Qty 1)

1шт.

8

NSS

NOT SOLD SEPARAT

Tube, Incl in 7

1шт.

9

238-6018

O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro

3шт.

10

201-317

ELBOW,45 Degree, 1 3/16"-12 x 1 1/16"-12. Adj, ORFS

ASSY, Incl 9 (Qty 1), 11, 13 (Qty 1)

1шт.

11

NSS

NOT SOLD SEPARAT

45° Elbow, Incl in 10

1шт.

12

84399339

HYDRAULIC HOSE,16mm ID x 1244mm L

Bucket Rod

1шт.

13

237-6012

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

2шт.

14

201-104

HYD CONNECTOR,1-3/16" - 12 Male ORFS x 1-1/16" - 12 Male ORB

ASSY, Incl 9 (Qty 1), 13 (Qty 1), 15

1шт.

15

NSS

NOT SOLD SEPARAT

1шт.

16

87393627

HYD CONNECTOR

ASSY, Incl 3, 17, 18

2шт.

17

NSS

NOT SOLD SEPARAT

Connector, Incl in 16

2шт.

18

167266

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

2шт.

19

43144

BOLT,Hex, M10 x 70mm, Cl 8.8

1шт.

20

84321337

SLEEVE,1245mm L

1шт.

21

D143846

CLAMP

3шт.

22

84408244

HOSE CLAMP

1шт.

23

120070

BOLT,Hex, M10 x 1.5 x 60mm, Cl 8.8

1шт.

24

412141

NUT,M10 x 1.5, Cl 8

3шт.

25

L18331

CABLE TIE,375.9mm L, Nylon, Black

2шт.

26

87655046

SPECIAL WASHER,10.65mm ID x 23mm OD x 2.2mm Thk

3шт.

27

43140

BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8

1шт.
