Запчасти Case 580SN WT (35.738.050) - HYDRAULIC LIFT, W/ MECHANICAL LIFT, VALVE, LINES, 4WD (35) - HYDRAULIC SYSTEMS
№
Артикул
Название
Примечание
Количество
1
84483241
BRACKET
Valve Mounting
1шт.
3
87655042
SPECIAL WASHER,8.8mm ID x 17.5mm OD x 2.2mm Thk
4шт.
4
9706690
NUT,M8 x 1.25, Cl 8
2шт.
5
86500688
NUT,Hex, M6 x 1.0, Cl 10.9
2шт.
6
87655041
SPECIAL WASHER,6.85mm ID x 13.5mm OD x 2mm Thk
4шт.
7
9850685
BOLT,Hex, M6 - 1 x 90mm, Cl 8.8
2шт.
8
L18331
CABLE TIE,375.9mm L, Nylon, Black
1шт.
9
84483473
HOSE,10mm ID x 1065mm L, SAE 100R6
Heavy Lift Return
1шт.
10
84989392
ELBOW,90 Degree, 11/16"-16 ORFS x 11/16"-16 Fem Sw
ASSY, Incl 14 (Qty 1), 26
1шт.
11
9993143
HYD CONNECTOR,11/16" - 16 ORFS x 9/16" - 18 ORB
ASSY, Incl 12, 13 (Qty 1), 14 (Qty 1)
1шт.
12
NSS
NOT SOLD SEPARAT
Connector, Incl in 11
1шт.
15
86596853
QUICK MALE COUPLING,9/16"-18
ASSY, Incl 13 (Qty 1), 16
1шт.
16
NSS
NOT SOLD SEPARAT
Coupler, Incl in 15
1шт.
17
84527720
CONTROL VALVE
ASSY, Heavy Lift Mechanical Control
1шт.
18
9840542
ELBOW,90 Degree, 9/16"-18 x 9/16"-18, Adj, ORFS
ASSY, Incl 13 (Qty 1), 29, 30
1шт.
19
84540599
HOSE,6.3mm ID x 880mm L, SAE 100R16 Type S
Heavy Lift
1шт.
20
84483235
HOSE,10mm ID x 842mm L, SAE 100R16 Type S
Heavy Lift
1шт.
21
87672176
HYD CONNECTOR
ASSY, Incl 14 (Qty 1), 27, 28
1шт.
22
H434163
DUST CAP
1шт.
23
9840330
HYD CONNECTOR,11/16" - 16 ORFS x 7/16" - 20 ORB
ASSY, Incl 14 (Qty 1), 24, 25
1шт.
24
NSS
NOT SOLD SEPARAT
Connector, Incl in 23
1шт.
25
165202
O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro
1шт.
26
NSS
NOT SOLD SEPARAT
90° Elbow, Incl in 10
1шт.
27
NSS
NOT SOLD SEPARAT
Connector, Incl in 21
1шт.
29
NSS
NOT SOLD SEPARAT
90° Elbow, Incl in 18
1шт.
Выбрано товаров: 30
