(10.402.05) - WATER PUMP - CONTROL (580SN, 580SN WT, 590SN)

Запчасти Case 580SN (10.402.05) - WATER PUMP - CONTROL (580SN, 580SN WT, 590SN) (10) - ENGINE

Схема запчастей Case 580SN - (10.402.05) - WATER PUMP - CONTROL (580SN, 580SN WT, 590SN) (10) - ENGINE
4
7
10
8
2
5
55.301.01
10.414.02
10.402.01
10.103.06
10.102.04
10.406.04
6
3
9
1
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

2856530

BRACKET

Support

1шт.

2

2852161

BELT TENSIONER

1шт.

3

2852162

PULLEY,65mm OD

1шт.

4

REF

INSTRUCTION

BELT

1шт.

5

4899079

SCREW,Hex Flg, M8 x 1.25 x 25

2шт.

6

4895292

FLANGE BOLT,Hex, M10 x 1.5 x 70mm

1шт.

7

REF

INSTRUCTION

ALTERNATOR

1шт.

8

REF

INSTRUCTION

PUMP Water

1шт.

9

REF

INSTRUCTION

DRIVE Fan

1шт.

10

REF

INSTRUCTION

PULLEY Crankshaft

1шт.

Выбрано товаров: 10
