Запчасти Case 580SN (10.500.AS[01]) - EXHAUST SYSTEM, DIESEL OXIDATION CATALYST (10) - ENGINE

1

47587890

CAN

DOC, Dosing Module & DEF Mixer

1шт.

2

47443351

CLAMP

Upper

1шт.

3

47443355

CLAMP

Lower

1шт.

4

614-10035

BOLT,Hex, M10 x 1.5 x 35mm, Cl 8.8, Full Thd

5шт.

5

896-15010

WASHER,11mm ID x 24mm OD x 3mm Thk

12шт.

6

829-1410

NUT,M10 x 1.5, Cl 10.9

9шт.

7

87417721

THREADED INSERT,M10 x 1.5-6H x 29 L

4шт.

8

896-11010

WASHER,11mm ID x 21mm OD x 2.5mm Thk

4шт.

9

811-10025

CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 25mm, Cl 8.8

7шт.

10

47727057

BRACKET

RH

1шт.

11

47727054

SUPPORT

DOC Mounting

1шт.

12

614-10025

BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8

2шт.

13

47727050

BRACKET

1шт.

14

47727059

BRACKET

LH

1шт.

15

47727052

BRACKET

Water Valve Mounting

1шт.

16

87301490

CLAMP,12.7mm, Coat, 10.3mm Bolt Hole, J Type

1шт.

17

614-8016

BOLT,Hex, M8 x 1.25 x 16mm, Cl 8.8, Full Thd

1шт.

18

829-1408

NUT,Hex, M8 x 1.25, Cl 10.9

1шт.
