(88.035.42[02]) - DIA KIT, NO AUX TO COMBO, EXTENDIBLE HOE, PILOT CONTROLS

Запчасти Case 580SN (88.035.42[02]) - DIA KIT, NO AUX TO COMBO, EXTENDIBLE HOE, PILOT CONTROLS (88) - ACCESSORIES

Схема запчастей Case 580SN - (88.035.42[02]) - DIA KIT, NO AUX TO COMBO, EXTENDIBLE HOE, PILOT CONTROLS (88) - ACCESSORIES
2
3
1
home
5
4
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

47360071

CONSTRUCTION DIA

NO AUX TO COMBO, EXTENDIBLE HOE, PILOT CONTROLS, Incl 2 - 5

1шт.

See Ref. 88.035.42 [01], 88.035.42 [03] to 88.035.42 [11]

1шт.

Refer to Installation Instructions for Correct Assembly Procedure

1шт.

2

84422094

CHECK VALVE

1шт.

3

84422097

SERVICE KIT

1шт.

4

NSS

NOT SOLD SEPARAT

1шт.

5

84422084

CHECK VALVE

Assy, Incl 2 - 4

1шт.
