Запчасти Case 580SN (88.035.28[02]) - DIA KIT, LOADER CONTROL VALVE, 3 SECTIONS - BUCKET SECTION, CLAM CYLINDER (PILOT CONTROLS) (88) - ACCESSORIES

1

84484676

SERVICE KIT

Loader Control Valve, 3 Sections, Bucket Section, Clam Cylinder (Pilot Controls), Incl 2 - 8, Serial Range: -`0

1шт.

See Ref. 88.035.28 [01]

1шт.

2

84157590

COMPENSATOR

1шт.

3

87346914

KIT

1шт.

4

84232746

PLUG

2шт.

5

85825473

SEAL KIT

1шт.

6

87617657

O-RING KIT

1шт.

7

NSS

NOT SOLD SEPARAT

Valve, Incl in 8

1шт.

8

84295102

HYD VALVE SECTION

Assy, Incl 2 - 7

1шт.
