Запчасти Case 580SN (88.100.55[07]) - DIA KIT, DIA, MECH - 3 SPL - P-SHIFT TRANS (88) - ACCESSORIES
![Схема запчастей Case 580SN - (88.100.55[07]) - DIA KIT, DIA, MECH - 3 SPL - P-SHIFT TRANS (88) - ACCESSORIES](https://partsell.ru/storage/images/casece/5380604.png)
90.160.am (01)
1
9
3
2
7
8
5
4
6
55.512.cl (11)
35.724.ae (01)
№
Артикул
Название
Примечание
Количество
1
47661824
CONSTRUCTION DIA
Kit, DIA MECH - 3 SPL - P-SHIFT TRANS, Incl 2 - 9
1шт.
2
Refer to Installation instruction 47661825 for Correct Assembly procedure
1шт.
2
47661825
INSTRUCTION
1шт.
3
87638044
JOYSTICK
Loader ontrol 3 Spool, ASSY
1шт.
4
256347A1
CONNECTOR, ELEC,Male, 4 Cavities
1шт.
5
258616A1
LOCK
1шт.
6
256341A1
ELEC CONNECTOR,Male, 2 Pin
1шт.
7
258613A1
LOCK
1шт.
8
239451A1
MULTIPOLE CONNECTOR,Female, 4 Pin
1шт.
9
225327C1
WEDGE,Lock, Black
1шт.
