Запчасти Case 580SN (21.134.AM[01]) - VAR - 423059 - TRANSMISSION, POWERSHUTTLE, CONTROL VALVE, 4WD (21) - TRANSMISSION

Схема запчастей Case 580SN - (21.134.AM[01]) - VAR - 423059 - TRANSMISSION, POWERSHUTTLE, CONTROL VALVE, 4WD (21) - TRANSMISSION
21.112.ac (02)
4
3
1
2
21.134.am (02)

Артикул

Название

Примечание

Количество

1

87524409

CONTROL VALVE

Powershuttle Transmission, 4WD, ASSY

1шт.

2

181207A1

PLATE

Feeding

1шт.

3

43133

BOLT,Hex, M8 x 1.25 x 80mm, Cl 8.8

6шт.

4

120228

HEX SOC SCREW,M8 x 20mm, Cl 8.8, Full Thd

3шт.

Выбрано товаров: 4
