Запчасти Case 580SN (55.512.350) - 3-SPOOL CONTROL VALVE, SEMI-POWERSHIFT, POWERSHIFT, TRANSMISSION, LOADER, JOYSTICK MOUNTING (55) - ELECTRICAL SYSTEMS

Схема запчастей Case 580SN - (55.512.350) - 3-SPOOL CONTROL VALVE, SEMI-POWERSHIFT, POWERSHIFT, TRANSMISSION, LOADER, JOYSTICK MOUNTING (55) - ELECTRICAL SYSTEMS
55.510.150
2
4
5
3
1
7
8
6
90.114.010
35.724.020
90.110.020
90.110.080
90.150.030
55.510.120
55.512.360

Артикул

Название

Примечание

Количество

1

87638044

JOYSTICK

ASSY, Loader Control 4 Button

1шт.

2

256347A1

CONNECTOR, ELEC,Male, 4 Cavities

1шт.

3

258616A1

LOCK

1шт.

4

256341A1

ELEC CONNECTOR,Male, 2 Pin

1шт.

5

258613A1

LOCK

1шт.

6

239451A1

MULTIPOLE CONNECTOR,Female, 4 Pin

1шт.

7

225327C1

WEDGE,Lock, Black

1шт.

8

47788201

CONSTRUCTION DIA

Loader Valve 3 Spool, Incl 1 - 7

1шт.

Valid for 580SN (Livery), 580SN WT (Livery), 590SN (Livery) Models Only, W/ Powershift Transmission

1шт.

To See Full DIA KIT Composition Look for all the Figures Where the DIA KIT P/N Is Shown

1шт.

8

47955704

CONSTRUCTION DIA

Loader Valve 3 Spool, Incl 1 - 7

1шт.

Valid for 580N (Livery) Model Only, W/ Pilot Control and Powershift Transmission

1шт.

To See Full DIA KIT Composition Look for all the Figures Where the DIA KIT P/N Is Shown

1шт.

8

47955719

CONSTRUCTION DIA

Loader Valve 3 Spool, Incl 1 - 7

1шт.

Valid for 580N (Livery) Model Only, W/ Mechanical Control and Powershift Transmission

1шт.

To See Full DIA KIT Composition Look for all the Figures Where the DIA KIT P/N Is Shown

1шт.

8

47955736

CONSTRUCTION DIA

Loader Valve 3 Spool, Incl 1 - 7

1шт.

Valid for 580SN (Livery), 580SN WT (Livery), 590SN (Livery) Models Only, W/ Mechanical Control and Powershift Transmission

1шт.

To See Full DIA KIT Composition Look for all the Figures Where the DIA KIT P/N Is Shown

1шт.

Выбрано товаров: 19
