Артикул
Название
Примечание
Количество
E46560
RESERVOIR
Incl. Ref 1 - 4; If Used
1шт.
1
NSS
NOT SOLD SEPARAT
RESERVOIR
1шт.
2
E47239
SEAL,6.5mm ID x 12mm OD x 10mm L
2шт.
3
E47238
PUMP,12V
MOTOR, 12 Volt
2шт.
4
E47240
PLUG
Cap
1шт.
5
614-8030
BOLT,Hex, M8 x 1.25 x 30mm, Cl 8.8, Full Thd
2шт.
6
496-41041
WASHER,13/32" x 1 1/8" x .134"
7шт.
7
832-10408
NUT,M8 x 1.25, Cl 8.8
2шт.
8
87428316
HOSE, BULK
HOSE, METERS 3150 mm (124-1/64 in); Front Washer; Cut From 1968141CX
1шт.
9
386718A3
GUARD
1630 mm (64-3/16 in); Cut From 397155A2
1шт.
10
284154A1
NOZZLE,3/8" - 16
Front; Includes A Steel and Rubber Washer Which Are Not Serviced Separately; Brass; If Used
1шт.
10
E43769
SPRAY
NOZZLE; Front; Includes Rubber Gasket; Plastic; If Used
1шт.
11
492-11038
LOCK WASHER,3/8"
If Used
1шт.
12
425-106
NUT,3/8"-16, Cl 5
If Used
1шт.
13
D147383
CLIP,5/8" J
J-Clamp, 5/8
1шт.
14
87423346
HOSE
6325 mm (249-1/64 in); Rear Washer; Cut From 1968141CX
1шт.
15
408966A1
GUARD
2200 mm (86-5/8 in); Rear Washer Hose; Lower; Cut From 397155A2
1шт.
15a
408965A1
GUARD
550 mm (21-11/16 in); Rear Washer Hose, Upper; Cut From 397155A2
1шт.
16
L18337
CABLE TIE,9.95"-12.1" lg
CABLE STRAP
6шт.
17
D147383
CLIP,5/8" J
J-Clamp, 5/8
1шт.
18
614-8016
BOLT,Hex, M8 x 1.25 x 16mm, Cl 8.8, Full Thd
1шт.
19
895-11008
WASHER,9mm ID x 16mm OD x 1.6mm Thk
1шт.
20
829-1408
NUT,Hex, M8 x 1.25, Cl 10.9
1шт.
21
87442441
GROMMET,27mm OD, 9.53mm ID, 11.1mm L
Washer, Hose
1шт.
22
E43769
SPRAY
Rear Nozzle; Includes Rubber Seal Which Is Not Serviced Separately
1шт.
23
386720A1
BRACKET
Rear Nozzle
1шт.
24
614-8020
BOLT,Hex, M8 x 1.25 x 20mm
1шт.
25
825-2408
FLANGE NUT,M8 x 1.25, Flg, Cl 8
1шт.
26
386785A1
WINDSHIELD WIPER SWI
Front Wiper
1шт.
27
386787A1
WINDSHIELD WASHER SW
Front
1шт.
28
386786A1
ROCKER SWITCH
Rear Wiper
1шт.
29
386788A1
WINDSHIELD WIPER SWI
Rear Washer
1шт.
30
87444176
HOSE CLIP
If Used
1шт.
31
87442924
BRACE
Used With E46560 Reservoir; If Used
1шт.
32
896-11008
WASHER,9mm ID x 17mm OD x 2mm Thk
3шт.
33
496-41041
WASHER,13/32" x 1 1/8" x .134"
4шт.
87448685
WINDSHIELD WASHER
RESERVOIR; Incl. Ref 34 - 38; If Used
1шт.
34
87449514
RESERVOIR, WINDSHIEL
2 Quart
1шт.
35
86507190
CAP
1шт.
36
86507198
PUMP,Windshield Washer
Component Parts Not Serviced Separately
2шт.
37
87449517
HOSE, BULK
HOSE, METERS 203 mm (8 in)
1шт.
38
L18337
CABLE TIE,9.95"-12.1" lg
CABLE STRAP Not Illustrated
1шт.
39
87448489
BRACKET
Replaces 87417223
1шт.
Выбрано товаров: 43
