Артикул
Название
Примечание
Количество
87737556
TOWER
Swing, Incl. 1 - 6
1шт.
1
140515A1
TOWER
Swing
1шт.
2
D151061
BUSHING,80.19mm ID x 100mm OD x 32mm L
2шт.
3
221476A1
BUSHING,80.19mm ID x 94mm OD x 23mm L
2шт.
4
D144170
BUSHING,80.19mm ID x 90mm OD x 20mm L
2шт.
5
D151060
BUSHING,70.19mm ID x 90mm OD x 30mm L
4шт.
11
139808A2
HYDRAULIC CYLINDER,Double Acting, 50.8mm Rod, 292mm Stroke
102 ID x 292 mm strk, Swing; See Figure 08-66
2шт.
11
139808A2R
REMAN-HYD CYLINDER
102 ID x 292 mm strk, Swing; See Figure 08-66
2шт.
11
139808A2C
CORE-HYD CYLINDER
Return Number
2шт.
12
198976A1
PLATE
Incl Ref 12A
1шт.
12a
114318A1
BUSHING,80.19mm ID x 90mm OD x 29.35mm L
80 x 90 x 29.3 mm
2шт.
13
827-20075
BOLT,Hex, M20 x 2.5 x 75mm, Cl 10.9, Full Thd
6шт.
15
829-1420
NUT,M20, Cl 10
6шт.
16
386092A2
PIN,50.77mm OD x 194.7mm L
2шт.
18
103-16200
SNAP RING,#200, Ext
4шт.
19
220489A1
LOCK WASHER
5 mm thk
1шт.
20
134167A1
SHIM,72mm ID x 140mm OD x 2.05mm Thk
2.05 mm (.08 in) thk
1шт.
21
175597A1
PIN,70mm OD x 175mm L
1шт.
22
D136700
SHIM,67mm ID x 83mm OD x 1.57mm Thk
1шт.
23
800-40070
SNAP RING,M70 Ext
2шт.
24
D136392
SHIM,72mm ID x 89mm OD x 3.05mm Thk
(M72 ID x 89 OD)
1шт.
25
D136700
SHIM,67mm ID x 83mm OD x 1.57mm Thk
1шт.
26
D136391
SHIM,72mm ID x 89mm OD x 1.57mm Thk
(M72 ID x 89 OD)
1шт.
27
800-40065
SNAP RING,M65, Ext
1шт.
28
219-1
LUBE NIPPLE,1/8" - 27 NPTF
1шт.
29
139262A1
PIN,70mm OD x 161mm L
1шт.
30
219-55
LUBE NIPPLE,90 Degree Elbow, 1/8" - 27 NPTF
1шт.
31
800-40065
SNAP RING,M65, Ext
1шт.
32
384967A1
PIN ASSY.
Swing Stop
1шт.
Выбрано товаров: 32
