Артикул
Название
Примечание
Количество
1
129015A1
SHAFT
1шт.
2
614-8025
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd
1шт.
3
832-10408
NUT,M8 x 1.25, Cl 8.8
1шт.
4
D59912
KNOB
Stabilizer Control Levers
2шт.
5
136267A1
LEVER
Boom; Incl. Ref 7
1шт.
6
136269A1
LEVER
Bucket; Incl. Ref 7
1шт.
7
D148992
BUSHING,19.15mm ID x 23.83mm OD x 10.6mm L
2шт.
8
136263A1
ROD,12.7mm OD x 407mm L
Dipper
1шт.
9
D150397
CRANK LEVER
Dipper
1шт.
10
425-118
NUT,1/2"-20, G5
3шт.
11
136261A1
THREADED ROD,1/2"-20 UNF x 260mm L
Stabilizer
2шт.
12
D150435
CRANK LEVER
Right-Hand Stabilizer Control
1шт.
13
D150434
CRANK LEVER
Left-Hand Stabilizer Control
1шт.
14
L54563
KNOB
Boom, Dipper, and Bucket
3шт.
15
A30881
SEALING WASHER,19.45mm ID x 31.35mm OD
49/64 x 1-15/64 x 1/32; Used As A Shim
1шт.
16
D34666
WASHER,33.34mm ID x 63.5mm OD x 2.38mm Thk
25/32 x 1-3/8 x 9/64; May Be Used In Place Of Ref 15
1шт.
17
D150486
SPACER,19.76mm ID x 25.4mm OD x 35mm L
Not Used On Models With Extendable Dipper
1шт.
18
D148994
SHAFT,182.10mm L
Swing
1шт.
19
D139039
BEARING ASSY,19mm ID
2шт.
20
614-8025
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd
4шт.
21
832-10408
NUT,M8 x 1.25, Cl 8.8
4шт.
22
213-126
ADJUSTABLE CLEVIS,3/8"-24 x 2 1/2"
3шт.
23
D149288
PIN,8.33mm OD x 30.66mm L
Special
3шт.
24
D150493
END
2шт.
25
427-6088
CLEVIS PIN,3/8" x 3/4"
2шт.
26
432-612
COTTER PIN,3/32" x 3/4"
5шт.
27
425-156
JAM NUT,Jam, 3/8"-24, G5
6шт.
28
87422243
THREADED ROD,9.53mm D x 368mm L
Left-Hand Stabilizer Control
1шт.
29
87422245
THREADED ROD,9.53mm D x 368mm L
Right-Hand Stabilizer Control
1шт.
30
87422247
THREADED ROD,9.53mm D x 352mm L
Dipper
1шт.
31
87422241
THREADED ROD,9.53mm D x 363mm L
Boom
1шт.
32
87422249
THREADED ROD,9.53mm D x 368mm L
Bucket
1шт.
33
87422239
THREADED ROD,9.53mm D x 151mm L
Swing
1шт.
34
D149295
BALL JOINT,3/8"
1шт.
36
425-116
NUT,3/8" - 24, Gr 5
1шт.
37
D149287
PIN,7.9mm OD x 26.72mm L
6шт.
38
432-612
COTTER PIN,3/32" x 3/4"
6шт.
39
136271A2
PEDAL
LH swing; Without Pilot Controls
1шт.
40
136270A2
PEDAL
RH swing; Without Pilot Controls
1шт.
41
219-1
LUBE NIPPLE,1/8" - 27 NPTF
2шт.
42
614-10025
BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8
4шт.
44
832-10410
NUT,M10 x 1.5, Cl 8
4шт.
45
D150503
END
Yoke
2шт.
46
D149262
CLEVIS,3/8-24"
3/8
2шт.
47
425-156
JAM NUT,Jam, 3/8"-24, G5
2шт.
48
D149288
PIN,8.33mm OD x 30.66mm L
3/8
4шт.
49
432-612
COTTER PIN,3/32" x 3/4"
4шт.
Выбрано товаров: 47
